Dialysis membrane produced from graphene

In a general sense, dialysis is the process by which molecules filter out of one solution, by diffusing through a membrane, into a more dilute solution.

Outside of hemodialysis, which removes waste from blood, scientists use dialysis to purify drugs, remove residue from chemical solutions, and isolate molecules for medical diagnosis, typically by allowing the materials to pass through a porous membrane.

Commercial dialysis membranes today, separate molecules slowly, in part due to their makeup: They are relatively thick, and the pores that tunnel through such dense membranes do so in winding paths, making it difficult for target molecules to quickly pass through.

From a sheet of graphene, a single layer of carbon atoms, MIT engineers have fabricated a functional dialysis membrane, linked end to end in hexagonal configuration like that of chicken wire. The graphene membrane, about the size of a fingernail, is less than 1nm thick. (The thinnest existing memranes are about 20nm thick.) The team’s membrane is able to filter out nanometer-sized molecules from aqueous solutions up to ten times faster than state-of-the-art membranes, with the graphene itself being up to 100 times faster.

While graphene has largely been explored for applications in electronics, Piran Kidambi, a postdoc in MIT’s Department of Mechanical Engineering, says the team’s findings demonstrate that graphene may improve membrane technology, particularly for lab-scale separation processes and potentially for hemodialysis.

“Because graphene is so thin, diffusion across it will be extremely fast,” Kidambi said. “A molecule doesn’t have to do this tedious job of going through all these tortuous pores in a thick membrane before exiting the other side. Moving graphene into this regime of biological separation is very exciting.”

Kidambi is a lead author of a study reporting the technology, published today in Advanced Materials. Six co-authors are from MIT, including Rohit Karnik, associate professor of mechanical engineering, and Jing Kong, associate professor of electrical engineering.

Plugging graphene

To make the graphene membrane, the researchers first used a common technique called chemical vapor deposition to grow graphene on copper foil. They then carefully etched away the copper and transferred the graphene to a supporting sheet of polycarbonate, studded throughout with pores large enough to let through any molecules that have passed through the graphene. The polycarbonate acts as a scaffold, keeping the ultrathin graphene from curling up on itself.

The researchers looked to turn graphene into a molecularly selective sieve, letting through only molecules of a certain size. To do so, they created tiny pores in the material by exposing the structure to oxygen plasma, a process by which oxygen, pumped into a plasma chamber, can etch away at materials.

“By tuning the oxygen plasma conditions, we can control the density and size of pores we make, in the areas where the graphene is pristine,” Kidambi said. “What happens is, an oxygen radical comes to a carbon atom [in graphene] and rapidly reacts, and they both fly out as carbon dioxide.”

What is left is a tiny hole in the graphene, where a carbon atom once sat. Kidambi and his colleagues found that the longer graphene is exposed to oxygen plasma, the larger and denser the pores will be. Relatively short exposure times, of about 45 to 60 seconds, generate very small pores.

Desirable defects

The researchers tested multiple graphene membranes with pores of varying sizes and distributions, placing each membrane in the middle of a diffusion chamber. They filled the chamber’s feed side with a solution containing various mixtures of molecules of different sizes, ranging from potassium chloride (0.66nm wide) to vitamin B12 (1-1.5nm) and lysozyme (4nm), a protein found in egg white. The other side of the chamber was filled with a dilute solution.

The team then measured the flow of molecules as they diffused through each graphene membrane.

Membranes with very small pores let through potassium chloride but not larger molecules such as L-tryptophan, which measures only 0.2nm wider. Membranes with larger pores let through correspondingly larger molecules.

The team carried out similar experiments with commercial dialysis membranes and found that, in comparison, the graphene membranes performed with higher ‘permeance,’ filtering out the desired molecules up to ten times faster.

Kidambi points out that the polycarbonate support is etched with pores that only take up 10% of its surface area, which limits the amount of desired molecules that ultimately pass through both layers.

“Only 10% of the membrane’s area is accessible, but even with that 10%, we’re able to do better than state-of-the-art,” Kidambi said.

To make the graphene membrane even better, the team plans to improve the polycarbonate support by etching more pores into the material to increase the membrane’s overall permeance. They are also working to further scale up the dimensions of the membrane, which currently measures 1 square centimeter.

Further tuning the oxygen plasma process to create tailored pores will also improve a membrane’s performance – something that Kidambi points out would have vastly different consequences for graphene in electronics applications.

“What’s exciting is, what’s not great for the electronics field is actually perfect in this [membrane dialysis] field,” Kidambi said. “In electronics, you want to minimize defects. Here you want to make defects of the right size. It goes to show the end use of the technology dictates what you want in the technology. That’s the key.”
