Digital oscilloscope delivers advanced debug capabilities

B&K Precision, a leading designer and manufacturer of reliable, cost-effective test and measurement instruments has announced its latest digital oscilloscope 2,560 series with DSO and MSO models.

The front panel boasts a large 8″ widescreen with 256-level color gradient, four analog channels, and logic analyzer. The logic analyzer software and 16-channel logic probe are included in the initial purchase of MSO models or can be upgraded in the field for DSO models.

The 2560 series consists of features customers have come to expect from modern digital oscilloscopes. These features include FFT, masking, pass/fail testing, waveform history, serial triggering and menu help. The powerful 25MHz function generator also comes standard in all models. Additionally, these oscilloscopes deliver advanced features and upgradable debug capabilities for a wide range of applications.

Key features of the new 2,560 series:

• 8″ widescreen color LCD display
• Compact footprint and lightweight
• 70, 100, 200, and 300MHz models
• 2GSa/s sample rate interleaved
• 140Mpts maximum record length
• 16 digital channels with logic analyzer (MSO upgrade)
• Serial bus decoding supporting I2C, SPI, UART/RS232, CAN, and LIN protocols (Decode upgrade)
• Function and Arbitrary Waveform Generator (AWG upgrade)
• 140,000wfms/s maximum waveform capture rate
• Standard LAN and USBTMC-compliant USB device port
