Glow-in-the-dark dye fueling our future

If someone came up with the idea of a glow-in-the-dark dye being the next advancement in energy storage technology, the scientists at the University of Buffalo would be on board.

And in fact they are. A fluorescent dye called BODIPY has been identified by researchers as a material for stockpiling energy in rechargeable, liquid-based batteries that could one day power cars and homes.

But the traits that facilitate energy storage are less visible. According to the researchers at the university, the dye has unusual chemical properties that enable it to excel at two key tasks: storing electrons and participating in electron transfer. Batteries must perform these functions to save and deliver energy, and BODIPY is very good at them.

In experiments, a BODIPY-based test battery operated efficiently and with longevity, running well after researchers drained and recharged it 100 times.

Lead Researcher Timothy Cook, PhD, an Assistant Professor of Chemistry in the University at Buffalo College of Arts and Sciences said: “As the world becomes more reliant on alternative energy sources, one of the huge questions we have is, ‘How do we store energy?’ What happens when the sun goes down at night, or when the wind stops?”

Cook continued: “All these energy sources are intermittent, so we need batteries that can store enough energy to power the average house.”

A dye-based battery of the future
BODIPY is a promising material for a liquid-based battery called a ‘redox flow battery.’

These fluid-filled power cells present several advantages over those made from conventional materials.

Lithium-ion batteries, for example, are risky in that they can catch fire if they break open. The dye-based batteries would not have this problem; if they ruptured, they would simply leak.

Redox flow batteries can also be easily enlarged to store more energy, enough to allow a homeowner to power a solar house overnight, for instance, or to enable a utility company to stockpile wind energy for peak usage times. This matters because scaling up has been a challenge for many other proposed battery technologies.

How BODIPY works in a battery
Redox flow batteries consist of two tanks of fluids separated by various barriers.

When the battery is being used, electrons are harvested from one tank and moved to the other, generating an electric current that, in theory, could power devices as small as a flashlight or as big as a house. To recharge the battery, you would use a solar, wind or other energy source to force the electrons back into the original tank, where they would be available to do their job again.

A redox flow battery’s effectiveness depends on the chemical properties of the fluids in each tank.

“The library of molecules used in redox flow batteries is currently small but is expected to grow significantly in coming years,” Cook said. “Our research identifies BODIPY dye as a promising candidate.”

In experiments, Cook’s team filled both tanks of a redox flow battery with the same solution: a powdered BODIPY dye called PM 567 dissolved in liquid.

Within this cocktail, the BODIPY compounds displayed a notable quality; they were able to give up and receive an electron without degrading as many other chemicals do. This trait enabled the dye to store electrons and facilitate their transfer between the battery’s two ends during repeated cycles, 100, of charging and draining.

Based on the experiments, scientists also predict that BODIPY batteries would be powerful enough to be useful to society, generating an estimated 2.3V of electricity.

Cook added that because the study focused on PM 567, different varieties of BODIPY share chemical properties; it is likely that other BOPIDY dyes would also make good energy storage candidates.

More information: EurekAlert!
