Pickering Showcases New Microwave Switch Design Tool at European Microwave Week 2024

September 2024 – Clacton-on-Sea, UK

Pickering Interfaces, the leading provider of modular signal switching & simulation products for electronic test & verification, will showcase its extensive range of RF & microwave switching, including SPDT, transfer, MUX and matrix switches with bandwidths from DC to 110GHz, available in PXI, LXI and USB – as well as the latest version of its Microwave Switch Design Tool plus new high channel count microwave MUX modules – on booth #142C at EuMW (European Microwave Week) 2024, at Paris Expo Porte de Versailles in Paris, France from September 24-26, 2024.

European Microwave Week (EuMW) is an annual series of events that began in 1998, featuring three co-located conferences: the European Microwave Conference (EuMC); the European Microwave Integrated Circuits Conference (EuMIC); and the European Radar Conference (EuRAD). Also part of EuMW, the European Microwave Exhibition is the largest trade show dedicated to microwaves & RF in Europe, providing 8,000 m² of exhibition space, around 4,000 visitors from around the globe, up to 1,700 conference delegates and in excess of 300 international exhibitors (from Asia and US, as well as Europe). It offers exhibitors an unrivalled opportunity to present RF & microwave products and technological developments, plus network with academics and professionals. It also provides a forum for discussing trends and exchanging technical information.

“The latest version of our Microwave Switch Design Tool – a powerful free online tool for configuring custom PXI and LXI microwave switch products with just a few clicks – has been updated to include schematic diagrams and simulation,” said Simon Aylott, Microwave Division Manager at Pickering Interfaces. “This accelerates the design to production process, from block diagram to mechanical layout, and minimizes risk by enabling you to design your own custom RF subsystem with an immediate visual indication of electrical performance.”

“Our new high channel count microwave MUX modules – based on superior-quality Radiall mechanical microwave switches, with bandwidth options from 8GHz to 40GHz, and versatile switching configurations, including single or dual SP8T, SP10T or SP12T multiplexers – deliver the highest RF and microwave switching performance available within a Pickering switching system.” noted Switching Product Manager at Pickering, Steve Edwards, “They are also the highest channel count microwave multiplexer switches available from any PXI vendor. This results in fewer switches and associated interconnections required for high channel count microwave switching applications, improved signal quality and ease of programming.”

In addition to its new Microwave Switch Design Tool and high channel count microwave MUX modules, Pickering will also highlight the following RFIU (RF switching insertion units) solutions on stand #142C at European Microwave Week (EuMW) 2024:

• MEMS-based PXI/PXIe RF multiplexers that deliver 300x operational life and 60x test system throughput compared to existing electromechanical relay products
• A configurable PXI microwave switch platform that allows RF test engineers to combine a wide range of high-performance relay types while minimizing chassis slot usage
• Flexible LXI microwave switch platform and turnkey services for LXI microwave switch and signal routing subsystems – including a 12×12 LXI microwave switching matrix demo

Pickering Interfaces stands behind its manufactured products with a standard three-year warranty and guaranteed long-term product support. Pricing, availability and contact information are supplied on its website at: www.pickeringtest.com

About Pickering Interfaces

Pickering Interfaces designs and manufactures modular signal switching & simulation for use in electronic test & verification. We offer the largest range of switching and simulation products in the industry for PXI, LXI, and PCI applications. We also provide cable and connector solutions, diagnostic test tools, and application software and drivers created by our in-house software team to support these products.

Pickering’s products are specified in test systems installed worldwide and have a reputation for providing excellent reliability and value. Pickering Interfaces operates globally with direct operations in the US, UK, Germany, Sweden, France, Czech Republic, and China, together with additional representation in countries throughout the Americas, Europe, and Asia. We serve all electronics industries, including automotive, aerospace & defense, energy, industrial, communications, medical, and semiconductor. For more information on signal switching & simulation products or sales contacts, please visit: www.pickeringtest.com
