Redriver reduces size and power use in automotive infotainment systems

Texas Instruments has revealed what it claims to be the industry’s first stand-alone USB 2.0 redriver.

The high speed, bidirectional TUSB211 redriver is AEC-Q100-qualified and designed to improve USB signal integrity in automotive infotainment systems.

It offers more than 40% lower power consumption than existing hub solutions; a small footprint with first-of-its-kind pinout to reduce overall solution size; and built-in calibration features to accelerate system evaluation and optimization.

These features enable designers to significantly reduce the size, cost and power consumption of automotive infotainment systems that offer navigation, mobile docking and other multimedia features.

Key features and benefits of TI’s TUSB211 redriver

• Simplified evaluation: Unlike existing hub solutions, with the TUSB211, there are no continuity breaks on the Printed Circuit Board (PCB). This allows flow-through of the existing signal and eliminates the need to break the traces when adding the redriver to the PCB.
• Ultra-low power consumption: The TUSB211 consumes less than 55mW in active mode – 40% lower power consumption than existing hub solutions – without compromising speed. It supports USB data rates up to 480Mbps.
• Small footprint: The redriver comes in a 1.6×1.6mm, 12-pin super-thin quad flat no-lead (X2QFN) package, offering a 60% smaller package size than the industry-standard package and removing the need for a large hub.
• Fully compliant to USB standards: The TUSB211 is compatible with USB1.0/1.1, USB 2.0, USB On-the-Go (OTG) and Battery Charging (BC) 1.2 protocols. The bidirectional capability of the device dynamically improves signal quality in both directions regardless of which device is host or peripheral.

Tools and support to speed design

To ease design of USB 2.0 systems, engineers can order an evaluation module (EVM), the TUSB211RPTREVM, which includes TI’s LP5907 single-channel LDO, for $199 from the TI store and authorized distributors.

Engineers can jump-start their designs with the USB 2.0, USB 3.0 re-driver dongleTI Designs reference design.

Engineers can also search for solutions, get help, share knowledge, and solve problems with fellow engineers and TI experts in the TI E2E™ Community Consumer and Computing and USB forums.
