Safe steering tech enables advanced safety for automated driving

Nexteer Automotive has announced the continued expansion of its automated driving portfolio with the introduction of two steering technologies that enable advanced safety and functions for Level 2-5 automated driving.

Nexteer’s high availability Electric Power Steering (EPS) and its advanced Steer-by-Wire (SbW) system were showcased at the 67^th IAA International Motor Show in Frankfurt, Germany.

Safety-Net is alwa­­ys on

“Similar to systems in aviation, our EPS system redundancies play an important safety, back-up function as the automotive industry moves toward varying levels of automation,” said Frank Lubischer, Nexteer’s CTO, CSO and Senior Vice President of Global Engineering.

“Nexteer’s steering safety net is always on.”

Nexteer’s EPS is designed for resilient operational availability.

It uses top-rated, high reliability components and intelligently optimized through additional redundancies in torque and position sensors.

As well as electronic control units, winding motors as well as dual sets of vehicle power and communication connectors.

High availability EPS facilitates Migration to SbW

“As OEMs continue investment in high availability EPS, the migration to Steer-by-Wire (SbW) becomes more cost-effective,” said Lubischer.

“Meanwhile, we enable easier SbW migration through our flexibility to support various packaging environments with our broad high availability EPS portfolio.

“This is an advantage to our customers, particularly during the transitional period when OEMs will likely carry SbW on a portion of a vehicle platform.

“An OEM can save a lot of investment and chassis redesign by leveraging our high availability EPS today with a future SbW migration in mind.”

Nexteer’s SbW: ‘Connects’ drivers to road feedback and real world steering feel

In SbW, the mechanical connection between the road wheels and the steering wheel is replaced with electronics and actuators on the column and rack.

This system supports both manual and automated driving and opens new possibilities for advanced safety features, vehicle light-weighting and packaging flexibility.

“While other SbW systems may give a numb or ‘video-game-like’ steering feel, our SbW offers a wide range of steering feel, including lively road feedback,” said Lubischer.

According to Lubischer, Nexteer’s SbW system is highly customizable to match an OEM’s DNA or brand character – from a sporty experience to a luxury steering feel.

SbW: Gateway to new safety advancements and automated steering

In addition to steering feel, SbW’s road feedback and road surface detection play important safety roles for the driver.

Lubischer explained that the steering system needs to communicate to the driver that he or she is on an icy road or slipping on loose gravel.

For example – even though the steering wheel and road wheels are electronically linked in a SbW system.

SbW also opens new possibilities for advanced safety functions, such as collision avoidance, stability control and more.

Advanced safety features can be implemented with the steering system alone or in combination with the braking system to achieve even higher safety levels.

ADAS

Lubischer also noted that Nexteer & Continental’s JV , CNXMotion, will combine Nexteer’s advanced steering systems with Continental’s advanced braking technologies into solutions for Automated Driving and Advanced Driving Assistance Systems (ADAS).

Nexteer considers its SbW as a foundational technology and exploring ways to create ‘well-informed steering systems’ of the future to increase driver safety.

As a key automated driving enabler, Nexteer’s SbW supports other advancements – such as Nexteer Steering on Demand System and Nexteer Quiet Wheel Steering.

Steering on demand

Steering on Demand enables the transition between the driver and automated driving control.

Through safe, intuitive steering transitions for vehicles capable of SAE Level 3, Level 4 and Level 5 automated driving.

The system also empowers the driver to tailor his driving experience through various driving performance options including a sport, comfort and manual override mode.

When driving in automated mode, Quiet Wheel Steering conveys safety and security by receding and remaining still – even while the road wheels are turning.
