IXYS Integrated Circuits Division (ICD) has announced the immediate availability of the CPC1010N, 250V, single-pole, normally open (1-Form-A) Solid State Relay (SSR) with a 170mA load current rating. The CPC1010N is specially designed to provide the best combination of performance, size and price.
Packaged in a 4-pin SOP, the CPC1010N employs optically coupled MOSFET technology to provide 1500Vrms of input to output isolation. The efficient MOSFET switches and isolated driver IC use IXYS ICD’s patented OptoMOS architecture and technology.
IXYS ICD’s advanced molded vertical construction makes the CPC1010N one of the world’s smallest relays and offers board space savings over the competitor’s larger 4-pin SOP relay. Additional features include low drive power requirements, high reliability, arc-free with no snubbing circuits, and no EMI/RFI generation. The CPC1010N is designed to replace, and offers superior reliability over, electromechanical relays.
The 250V load voltage rating, 170mA load current rating and 11.5Ω of on-resistance makes this device suitable for industrial applications, instrumentation, multiplexers, data acquisition, and electronic switching.
Approvals include: UL Recognized Component: File E76270, CSA Certified Component: Certificate 1172007, EN/IEC 60950-1 Certified Component: TUV Certificate B 13 12 82667 003. The CPC1010N SSR is available in production quantities.
