StarRC technology files available in 28nm PDK

It has been announced that China’s largest and most advanced semiconductor foundry and one of the world’s largest foundries, Semiconductor Manufacturing International Corporation SMIC, and Synopsys, have adopted Synopsys’ StarRC product as the standard solution for signoff parasitic extraction for its 28nm process technology.

This standardization is a result of a growing collaboration between SMIC and Synopsys to provide best-in-class solutions to mutual customers to meet their increasing needs for accuracy, performance and efficiency at advanced nodes. The StarRC solution delivered silicon-accurate extraction and productivity validated by SMIC for its 28nm process. The qualified StarRC technology files are available as the default in SMIC’s 28nm Process Design Kits (PDKs) for both digital and custom designs.

“Continuing to build on the momentum of our 28nm process technology, a favorite node for semiconductor companies is a priority for us, and the availability of qualified design tools is critical to support our expanding global customer base,” said Anderson Huang, Senior Director of Technology Development at SMIC.

Huang continued: “The partnership with Synopsys represents an enduring commitment to providing customers with the high-quality technologies and standards for use with our world-class manufacturing process. The deployment of StarRC in our 28nm PDKs bolsters the resources available to our mutual customers through StarRC’s proven silicon accuracy and comprehensive capabilities for both digital and custom designs, allowing them to develop advanced designs with increased confidence and productivity.”

The StarRC product, an integral part of the Synopsys Galaxy Design Platform signoff solution, is industry gold standard for gate-level and transistor-level parasitic extraction. It achieves superior performance and efficiency with its ultra-scalable multi-core architecture, Simultaneous Multi-Corner (SMC) extraction and fast ECO capabilities, while maintaining industry-standard golden accuracy.

The StarRC product provides extraction capabilities across a wide range of applications, from 100+ million instance digital System-On-Chip (SoC) designs to custom memory, IP, standard cell and analog designs. Integration with Synopsys IC Compiler II place and route and PrimeTime static timing analysis solutions allows designers to achieve even faster ECO design closure, while reducing disk space and processor core resources. In custom design environments, designers can cross-probe between parasitic and schematic views, annotate schematics with parasitics and perform visual debug.

Significantly faster simulation runtimes and reduced disk space resources are realized through highly optimized extraction tuned for performance. The result of the collaboration between SMIC and Synopsys delivers qualified StarRC technology files in SMIC’s 28nm PDK that enable mutual customers to use a silicon-accurate and efficient extraction solution for their designs targeting SMIC’s 28nm node.

“Meeting customers’ increasing needs to address complexity and accelerate design and analysis cycles are critical to propel them to silicon success at advanced process technologies,” said Bijan Kiani, Vice President of Marketing for the Design Group at Synopsys.

Kiani added: “SMIC’s standardization on StarRC for parasitic extraction for its 28nm process technology highlights the strong trust in our technology to deliver on these important requirements and supports the innovations being driven by our mutual customers.”
