Where To Start With Starter Development Kits: SimpleLink LaunchPad Dev Kit

The SimpleLink MSP432P401R LaunchPad development kit from Texas Instruments enables you to develop high-performance applications that benefit from low power operation. In addition, it features the MSP432P401R and this includes a 48MHz ARM Cortex-M4F, 80uA/MHz active power and 660nA RTC operation, 14-bit 1MSPS differential SAR ADC and AES256 accelerator.

All pins of the MSP-EXP432P401R device are fanned out for easy access, so this makes it easy to plug in 20-pin and 40-pin BoosterPack modules. The modules add additional functionality including Bluetooth low energy and WiFi wireless connectivity.

  • What is the SimpleLink MSP432P401R LaunchPad for? High performance, low-power applications.
  • How much does the SimpleLink MSP432P401R LaunchPad cost? Currently available at $12.99.
  • What’s in the box? LaunchPad Development Kit, Micro-USB cable, Quick start guide.

Tech Specs of the SimpleLink MSP432P401R LaunchPad

Power High performance, low-power MSP432P401R MCU
Power consumption 80uA/MHz active and 660nA RTC standby operation
Analog 24Ch 14-bit differential 1MSPS SAR ADC, two comparators
Digital Advanced ecryption standard (AES256) accelerator, CRC, DMA, HW MPY32
Memory 256KB Flash, 64KB RAM
Timers Four times 16-bit, and two times 32-bit
Communication Up to four I2C, eight SPI, four UART
Connector 40 pin BoosterPack Connector, and support for 20 pin BoosterPacks
SimpleLink MSP432P401R LaunchPad Development Kit
Credit: Texas Instruments

Documentation

Source Texas Instruments
