Tiny three phase Book Style EMC filter

When developed with appropriately sized EMC filters during the start of the design-in phase, machines and installations can be optimized to meet the EMC standards from the outset.

These latest Schaffner filters are based on a new design structure, resulting in a significant footprint reduction and have their connection terminals integrated within the filter enclosure.

With the new FN 3287 and FN 3288 product series Schaffner can provide very compact and widely usable solutions from 10 to 160A providing standard or high-attenuation performance requirements in addition to low leakage current fulfillment.

The FN 3287 and FN 3288 series are available with 11 current ratings from ten to 160A. Both series are available for 480VAC and the FN 3288 series also for 690VAC and IT network applications.

All models are CE, UL and ENEC approved and RoHS compliant.
