VCO Operates From 3420 To 3430MHz

Crystek’s CVCO55CC-3420-3430 VCO (Voltage Controlled Oscillator) operates from 3420 MHz to 3430 MHz with a control voltage range of 0.5 V~4.5 V. This VCO features a typical phase noise of -110 dBc/Hz @ 10KHz offset and has excellent linearity. Output power is typically +2.0 dBm.

Engineered and manufactured in the USA, the model CVCO55CC-3420-3430 is packaged in the industry-standard 0.5-in. x 0.5-in. SMD package. Input voltage is typ. 5.0 V, with a max. current consumption of 23 mA. Pulling and Pushing are minimized to 1.0 MHz and 1.0 MHz/V, respectively. Second harmonic suppression is -15 dBc typical.

The CVCO55CC-3420-3430 is ideal for use in applications such as digital radio equipment, fixed wireless access, satellite communications systems, and base stations.
