The term ‘via’ probably comes from the Latin word meaning ‘road’. Therefore, open via would essentially mean ‘open road’. Open roads, here in Oregon sometimes run through open range ranch land. That means that cows have as much right to be on the road as do cars. If you don’t want cows on your PC boards where the BGAs go, don’t leave open vias in your BGA footprint.
By Duane Benson, Chief Technology Champion at Screaming Circuits
Your assembled board will likely be missing connection between some of the BGA balls and the board. That’s almost as bad as having a cow step on it. If you are putting the via IN the BGA pad, your only choice is to have the vias filled and plated over at the board fab house. There are many reasons you shouldn’t use via in pad. It’s not good practice, and those via holes act like little capillary straws and suck solder off of the pad or the BGA.
That said there are some applications that may require, or seem to require, via in pad. Here are a few examples of why you might need to use via in pad:
- If there is not enough space on the board.
- It can help with thermal management.
- Trace routing may be easier with via in pad.
- High frequency designs benefit from the shortest possible routing to bypass capacitors, which may indicate via in pad.
So if you don’t have a choice, here are some methods you can try when using via in pad:
- Have the board fab house plug the via and then plate copper over it. This is our favorite option. It will give you all of the benefits of via in pad without causing problems in assembly. It’s really our only recommended via-in-pad method.
- Use a micro-via that only goes through one layer of the board. Although this may be an okay option, the solder can still wander down into the via, leaving voids.
- Cap the underside of the board with solder mask. This is our least favorite option because sometimes the cap can pop open, and the void may be big enough to still pull too much of the solder off of the pad.
If you’re putting the vias between the pads, you have two options. You can put soldermask dams on the short trace between the pad and the open via. This will prevent solder paste from migrating. The other, and better, option is to cap the vias with solder mask. This gives a bit of extra protection in case any of the solder mask dams are too thin or chip off. Just make sure you cap these things on the solder side. If you cap them on the back, solder can still spread on the trace and partway into the via. That still puts the electrical and mechanical connection at risk.
